Product
SS255-SS550 PPGI
The galvanized steel sheets are a rugged and long-lasting option for outdoor work. Manufactured by a coating steel sheet with a layer of zinc, SS255-SS550 PPGI sheets are a great resistant to scratches, corrosion, and other damages. This product is made by cleansing the heat-treated rolled PPGI Coils and then dipped into a bath of molten zinc.
Parameter
Wholesale rectangular steel pipe manufacturer-pre-coated GI/PPGI/PPGL color coated galvanized steel roof slab：
| Material | The steel is submerged in a zinc container so it can be fully covered with the metal. It contains 240-275g/sqm zinc which provides excellent protection against corrosion. |
| Thickness | 0.12-1.0mm |
| Width | 600-1000mm (after corrugated) |
| Length | 1000-12000mm |
| Zinc Coating | Z40-275g/sqm |
| Paint Top | 15 – 35 Microns |
| Paint Back | 5 – 35 Microns |
| Coating Color | ALL RAL Cards Color |
| Coating Type | Top Painted : PVDF / HDP / SMP / PE / PU Primer Painted : Polyurethane / Epoxy / PE Back Painted : Epoxy / Modified Polyester |
| Weight Per Bundle | 2-5 tons |
SS255-SS550 PPGI
SS255-SS550 PPGI is 0.12-1.0mm thick, 600-1000mm in width(after corrugated), and 1000-12000mm long which makes them durable and offer great resistance to bending, warping, and impact.
| PPGI | Paint Line 1 | Paint Line 2 | Paint Line 3 |
| Material Thickness | 0.25 – 1.50 mm | 0.25 – 1.20 mm | 0,25-1,20 mm |
| Width | 900 – 1300 mm | 900 – 1300 mm | 900 – 1300 mm |
| Coil Inner Diameter | 508 mm | 508 mm | 508 mm |
| Maximum Roll Weight | 11 Tons | 11 Tons | 11 Tons |
These sheets are coated with zinc which provides a continuous barrier against moisture and oxygen reaching the steel and offers base steel a great protection. They can form high structural solidity in roofing panels, load-bearing beams, and heavy snow areas. The double-layer protection (painted top and painted back) provides additional protection against corrosion as steel is susceptible to rust.
| CONTINUOUSLY HOT-DIP COATED STEEL FLAT PRODUCTS FOR COLD FORMING (TS EN 10346 / TS EN 10169) | |||||||||||
| No | Steel Quality | Steel Number | Coating Type | Chemical Composition ( % ) Max | Yield Strength( N/mm2 ) | Tensile Strength( N/mm2 ) | Elongation ( % ) Min | ||||
| C | Si | Mn | P | S | |||||||
| 1 | DX51D | 1.0917 | +Z | 0,18 | 0,50 | 1,20 | 0,12 | 0,045 | * | 270-500 | 22 |
| +AZ | |||||||||||
| 2 | DX52D | 1.0918 | +Z | 0,12 | 0,50 | 0,60 | 0,10 | 0,05 | 140 – 300 | 270 – 420 | 26 |
| +AZ | |||||||||||
| 3 | DX53D | 1.0951 | +Z | 140 – 260 | 270 – 380 | 30 | |||||
| +AZ | |||||||||||
| 4 | DX54D | 1.0952 | +Z | 120 – 220 | 260 – 350 | 36 | |||||
| +AZ | |||||||||||
| 5 | S220GD | 1.0241 | +Z | 0,20 | 0,60 | 1,70 | 0,10 | 0,045 | Min 220 | Min 300 | 20 |
| +AZ | |||||||||||
| 6 | S250GD | 1.0242 | +Z | Min 250 | Min 330 | 19 | |||||
| +AZ | |||||||||||
| 7 | S280GD | 1.0244 | +Z | Min 280 | Min 280 | 18 | |||||
| +AZ | |||||||||||
| 8 | S320GD | 1.0250 | +Z | Min 320 | Min 360 | 17 | |||||
| +AZ | |||||||||||
| 9 | S350GD | 1.0529 | +Z | Min 350 | Min 390 | 16 | |||||
| +AZ | |||||||||||
| 10 | S390GD | 1.0238 | +Z | Min 390 | Min 460 | 16 | |||||
| +AZ | |||||||||||
| 11 | S420GD | 1.0239 | +Z | Min 420 | Min 480 | 15 | |||||
| +AZ | |||||||||||
| 12 | S450GD | 1.0233 | +Z | Min 450 | Min 510 | 14 | |||||
| +AZ | |||||||||||
| 13 | S550GD | 1.0531 | +Z | Min 550 | Min 560 | – | |||||
| +AZ | |||||||||||
It is used in industries where it is treated with harmful chemicals or products. It also contains hermetic separation against atmospheric agents that help them to remain outdoors for a long time. They are durable and have a beautiful appearance thus they don’t need many late finishes after installation. From roofing to wall cladding, gutters, and downspouts, to furniture and interior designs, they have unlimited applications.
