316 Stainless Steel Plate
Our 316 stainless steel plates offer outstanding durability and superior resistance to corrosion, even in the toughest conditions. This steel plate functions well under challenging environments where it serves applications throughout marine environments as well as pharmaceutical and chemical sectors, making it perfect for long-term, reliable performance. With excellent weldability and structural strength, our stainless steel plates ensure easy fabrication and long-lasting industrial use. Get high-quality 316 Stainless Steel Plates from Foursteels, so contact us and get a quote now!
Parameter
316 Stainless Steel Plate Composition, and Applications
Our 316 Stainless Steel Plate utilizes chromium levels between 16-18% for corrosion protection and combines this with 10-14% nickel for durability as well as 2-3% molybdenum addition for better pitting and crevice corrosion resistance. It also contains 2% max manganese for added strength, while silicon maintains oxidation resistance at 1% max and carbon stays below 0.08% max. Finally, phosphorus levels are kept to under 0.045% maximum, as well as sulfur, to maintain its excellent machinability and weldability. The material’s specific chemical makeup provides exceptional durability in all extreme environments, such as chemical substances and marine conditions.
| Specification | Stainless Steel Plate(Hot rolled, cold rolled) |
| Standard | ASTM A240, JIS4304-2005, ASTM A167, EN10088-2-2005, GB/T3280-2007, etc |
| Material | 201, 202, 304, 304L, 304H, 309, 309s, 316, 316L, 317, 317L, 321, 321H, 310, 347, 347H, 410, 416, 420, 430, 440, 904, 904L |
| Surface | the surface and finish of stainless steel Plate:2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, checkered, embossed, hair line, sandblast, Brush, etching, etc |
| Thickness | 5mm-100mm |
| Width | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Length | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Brand: | Kuwait Origin, European Origin, Japanese Origin, US Origin, Korea Origin, Taiwan Origin |
| Manufacturer: | POSCO, Aperam, Jindal Stainless, DKC Korea, Thyssenkrup, Baosteel, TISCO, Arcelor Mittal, VDM, Nippon Metal, Outokumpu |
| Package | Standard export package, suit for all kinds of transport, or as required. |
| Grade | C (Max) | Mn (Max) | P (Max) | S (Max) | Si (Max) | Cr | Ni | Mo | Nitrogen (Max) | Cu/ Others |
| 301 | 0.15 | 2.00 | 0.045 | 0.030 | 1.00 | 16.00 – 18.00 | 6.00 – 8.00 | – | 0.10 | – |
| 304 | 0.08 | 2.00 | 0.045 | 0.030 | 0.75 | 18.00 – 20.00 | 8.00- 10.50 | – | 0.10 | – |
| 310S | 0.08 | 2.00 | 0.045 | 0.030 | 1.50 | 24.00- 26.00 | 19.00 – 22.00 | – | – | – |
| 316 | 0.08 | 2.00 | 0.045 | 0.030 | 0.75 | 16.00 – 18.00 | 10.00 – 14.00 | 2.00 – 3.00 | 0.10 | – |
| 316L | 0.030 | 2.00 | 0.045 | 0.030 | 0.75 | 16.00 – 18.00 | 10.00 – 14.00 | 2.00 – 3.00 | 0.10 | – |
| 321 | 0.08 | 2.00 | 0.045 | 0.030 | 0.75 | 17.00 – 19.00 | 9.00 – 12.00 | – | 0.10 | Ti5 ( C + N ) Min or 0.70 max |
| 409 | 0.08 | 1.00 | 0.040 | 0.010 | 1.00 | 10.50 – 11.75 | 0.50 | – | – | Ti= 6x (C+ N ) Min or 0.70 Max |
| 410 | 0.15 | 1.00 | 0.040 | 0.030 | 1.00 | 11.50- 13.50 | 0.75 | – | – | – |
| Grade | TensileStrength Mpa, (Min) | YieldStrengthMpa, (Min) | %AgeElongationin 50mmgauge length min | Hardness (Max) | |
| BHN | Rb | ||||
| 304 | 515 | 205 | 40 | 201 | 92 |
| 310S | 515 | 205 | 40 | 217 | 95 |
| 316 | 515 | 205 | 40 | 217 | 95 |
| 317 | 515 | 205 | 35 | 217 | 95 |
| 317L | 515 | 205 | 40 | 217 | 95 |
| 321 | 515 | 205 | 40 | 217 | 95 |
| 409 | 380 | 170 | 20 | 179 | 88 |
| 410S | 415 | 205 | 22 | 183 | 89 |
| 410 | 450 | 205 | 20 | 217 | 89 |
We provide a wide selection of finishes, which includes 2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, checkered, embossed, hairline, sandblasted, Brushed and etched finishes to meet various application needs. Common applications include marine structures, pharmaceutical equipment, food processing, heat exchangers and industrial components.
